DS1-F03

Power Line Filter Modules Overview

The DS1-F03 is a single-phase EMC/EMI power line filter module manufactured by DIT (Dong IL Technology). It is rated for an AC voltage of 250V and a continuous current of 3A, operating at frequencies between 50Hz and 60Hz. The unit features a single-stage filtering configuration with quick-connect terminals and chassis mounting. It is certified by CSA, TUV, and UR agencies.

Power Line Filter Modules Feature Summary

• Utilizes a metal case to provide effective electromagnetic shielding
• Delivers excellent filtering characteristics for both differential mode and common mode noise

Power Line Filter Modules Applications

• General purpose electronic equipment requiring EMI suppression
• Industrial control systems
• Commercial machinery

Power Line Filter Modules Procurement Notes

Verify the specific manufacturer part number DS1-F03 against official Dong IL Technology documentation to confirm electrical ratings and certification marks. Ensure compatibility with 250VAC/DC systems and 3A load requirements. Confirm that quick-connect terminal types match existing wiring harnesses before procurement.

Power Line Filter Modules Selection Notes

Select this component when a compact, single-phase filter is required for 3A applications. The metal enclosure offers superior shielding compared to plastic alternatives. Verify that the chassis mount style fits the available panel space and that quick-connect terminals are suitable for the intended circuit connections.

Power Line Filter Modules Part Context

This component belongs to the DS1 series of power line filter modules from Dong IL Technology. The series includes various current ratings, such as the DS1-F10 for 10A applications. These filters are designed for general-purpose EMI/EMC suppression in AC power lines.

Power Line Filter Modules Replacement Considerations

Check for direct substitutes within the DS1 series, such as the DS1-F05 or DS1-F10, if higher current capacity is needed. Ensure any replacement maintains the same 250V rating, 50-60Hz frequency range, and quick-connect termination style.
