DS1-F05

Power Line Filter Modules Overview

The DS1-F05 is a single-phase EMC/EMI line filter module manufactured by Dong Il Technology Ltd. It is designed for chassis mounting and features quick connect terminals for easy integration into power systems. The component operates with a rated current of 5 A and supports voltage levels up to 250 VAC/VDC. It functions as a single-stage filter suitable for frequencies between 50 Hz and 60 Hz, providing noise suppression for connected equipment.

Power Line Filter Modules Feature Summary

• Provides effective shielding through the use of a metal case construction
• Delivers excellent filtering characteristics for both differential mode and common mode interference
• Designed for reliable performance in industrial and commercial environments

Power Line Filter Modules Applications

• Factory automation (FA) equipment
• Industrial control systems
• Commercial machinery requiring EMI/EMC compliance

Power Line Filter Modules Procurement Notes

Verify the manufacturer designation carefully, as DIT may refer to different entities. Confirm that the supplier is authorized by Dong Il Technology Ltd. Ensure the specific part number matches the required electrical ratings and physical dimensions before ordering, as availability and lead times vary by region.

Power Line Filter Modules Selection Notes

Select this component when chassis-mounting is required for single-phase applications. Ensure the operating environment temperature falls within the specified range of -25°C to 85°C. Verify that the load current does not exceed 5 A and that the system voltage is compatible with the 250 VAC/VDC rating.

Power Line Filter Modules Part Context

This component belongs to the DS1 series of power line filter modules produced by Dong Il Technology Ltd. These filters are engineered to mitigate electromagnetic interference in AC power lines. The series typically includes various current and voltage ratings to suit different industrial standards and equipment requirements.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer's official catalog for direct equivalents or cross-reference based on identical electrical specifications and mounting configurations.
