DS1-F08

Power Line Filter Modules Overview

The DS1-F08 is a single-phase EMC/EMI line filter module manufactured by DIT. It is designed for chassis mounting and features quick-connect terminals for rapid installation. The component supports a continuous current rating of 8 A and operates with voltage ratings up to 250 VAC/VDC. It functions within a frequency range of 50 to 60 Hz and utilizes a single-stage filtering architecture.

Power Line Filter Modules Feature Summary

• Single-phase EMC/EMI line filtering
• Chassis mount design
• Quick connect terminal interface

Power Line Filter Modules Applications

• Industrial equipment power input protection
• Electronic device EMI suppression
• Power supply line filtering

Power Line Filter Modules Procurement Notes

Verify the manufacturer part number DS1-F08 against official DIT documentation to confirm specifications. Ensure compatibility with 250VAC/VDC systems and 8A load requirements. Check for standard lead times, which may extend to approximately 40 weeks. Confirm chassis mounting dimensions and quick-connect terminal types match system integration needs before ordering.

Power Line Filter Modules Selection Notes

Select this component for applications requiring single-phase noise reduction in power lines. It is suitable for environments operating at 50-60Hz. Consider the 8A current capacity and 250V voltage rating when designing circuits. The chassis mount style requires appropriate panel space and mechanical support.

Power Line Filter Modules Part Context

This component belongs to the DIT power line filter modules category. It serves as an electromagnetic interference suppression device for AC power inputs. The product is distinct from digital transformer architectures or consumer appliances sharing similar alphanumeric codes.

Power Line Filter Modules Replacement Considerations

Consult official DIT documentation for verified substitute part numbers. Cross-reference electrical ratings and physical dimensions to ensure functional equivalence.
