Product Detailed Parameters
- Description：IC TRANSCEIVER 0/1 SOT235
- Mfr：Texas Instruments
- Package：Tape & Reel (TR)
- Series：-
- Type：Receiver
- Protocol：LVDS
- Number of Drivers/Receivers：0/1
- Duplex：-
- Data Rate：400Mbps
- Voltage - Supply：3V ~ 3.6V
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：Surface Mount
- Package / Case：SC-74A, SOT-753
- Supplier Device Package：SOT-23-5
- Receiver Hysteresis：-
- Grade：-
- Qualification：-
Download product information
Overview
The DS90LT012ATMFX/NOPB is a single LVDS line receiver manufactured by Texas Instruments. It operates within a supply voltage range of 2.7 V to 3.6 V, with a typical operating voltage of 3.3 V and a quiescent current of 9 mA. The device supports data rates up to 400 Mb/s and features an LVDS differential input paired with an LVTTL output. Key electrical parameters include a propagation delay of 3.5 ns and an input voltage range from -100 mV to 0 V. It is housed in a compact SOT-23-5 surface-mount package and functions reliably across an industrial temperature range of -40°C to +85°C.
Feature Summary
- Converts low-voltage differential signaling (LVDS) inputs to logic-compatible LVTTL outputs for digital interfacing.
Applications
- High-speed serial data communication links requiring signal conversion.
Procurement Notes
Verify the exact part number against official manufacturer documentation to ensure compatibility with system requirements. Confirm that the specific suffix matches the intended packaging configuration. Cross-reference specifications such as voltage levels and package dimensions with the latest datasheet before finalizing procurement decisions.
Selection Notes
Select this component when a single-channel LVDS-to-LVTTL conversion is required in space-constrained designs. Ensure the application environment stays within the specified -40°C to +85°C temperature range. Verify that the 3.3 V supply voltage aligns with the target system's power architecture and that the 400 Mb/s speed meets the data throughput needs.
Part Context
This device belongs to the DS90LV012A series of LVDS interface integrated circuits. It serves as a complementary component to drivers like the DS90LV011A, providing the receiving end of a differential link. The series is designed for robust high-speed data transmission in consumer and industrial electronics where noise immunity and low power consumption are critical.
Replacement Considerations
The DS90LV012ATMF/NOPB is functionally equivalent regarding core specifications but differs in reel packaging quantity. Verify pinout compatibility and electrical characteristics before substituting.
