DSPIC30F1010T-30I/MM

Microcontrollers Overview

The DSPIC30F1010T-30I/MM is a 16-bit Digital Signal Controller from the dsPIC30F SMPS family, manufactured by Microchip Technology. It features 2 Kbytes of Flash program memory and operates at a maximum clock frequency of 30 MHz. The device utilizes a 28-pin QFN package (MM suffix) and supports an operating temperature range of -40°C to +85°C. It lacks data EEPROM but includes specialized programming capabilities for Switched Mode Power Supply applications.

Microcontrollers Feature Summary

• Supports Enhanced In-Circuit Serial Programming via a dedicated on-chip programming executive for faster device configuration.
• Includes a reserved executive code memory region that facilitates master-slave interaction with external programmers.
• Provides configurable CodeGuard security bits to manage read and write protection for boot and general program segments.

Microcontrollers Applications

• Third-party tool development for dsPIC30F SMPS device programming
• Digital power conversion systems requiring specific flash programming protocols
• Switched Mode Power Supply controller implementations

Microcontrollers Procurement Notes

Verify the specific MM package variant against the official datasheet to ensure pin compatibility. Confirm that the programming environment supports the Enhanced ICSP protocol required for this SMPS family. Check for any Product Change Notifications regarding packaging or material composition updates prior to finalizing procurement specifications.

Microcontrollers Selection Notes

Select this component when designing systems that require the specific flash programming architecture defined in the dsPIC30F SMPS specification. Ensure the design accommodates the absence of data EEPROM. Verify that the chosen programmer hardware can generate the required 32-bit serial key sequence for entering programming modes.

Microcontrollers Part Context

This part belongs to the dsPIC30F SMPS family, which shares programming characteristics with other devices like the dsPIC30F2020 and dsPIC30F2023. It differs from standard dsPIC30F devices by its specific entry mechanism into programming modes and the presence of a programming executive in reserved memory.

Microcontrollers Replacement Considerations

Direct substitutes within the same family include the dsPIC30F2020 and dsPIC30F2023, though these offer larger code memory sizes. Verify pinout and memory map compatibility before substitution.
