DST-6-36

Overview

The DST-6-36 is a Class 2 laminated power transformer from the DST series, designed for board mount applications. It features dual primary windings rated for 115 VAC and 230 VAC input voltages. The secondary configuration provides a center-tapped output of 36 VCT at 0.55 A and an additional 18 V winding at 1.1 A. With a total power rating of 20 VA, this component utilizes through-hole mounting technology and operates at standard 50/60 Hz frequencies.

Feature Summary

• Dual cavity platform design for enhanced isolation
• Split bobbin construction to minimize leakage inductance
• Class 2 safety compliance for low-energy circuits
• Laminated core structure for efficient magnetic coupling

Applications

• Industrial control panel power supplies
• Servo drive system auxiliary power
• General purpose electronic equipment transformers
• Low voltage AC distribution modules

Procurement Notes

Verify the specific pinout configuration against the official datasheet before integration, as terminal arrangements may vary between manufacturing batches. Confirm that the receiving facility supports through-hole assembly processes compatible with the component's lead specifications. Ensure that the application environment remains within the thermal limits defined by the manufacturer to maintain long-term reliability and insulation integrity.

Selection Notes

Select this model when a split secondary output is required for rectification or biasing purposes. The dual primary capability allows flexibility for international voltage standards without rewiring changes. Consider the physical dimensions and weight constraints of the enclosure, as laminated core transformers are heavier than switch-mode alternatives. Verify that the 20 VA rating meets the peak load requirements of the downstream circuitry during startup conditions.

Part Context

This component belongs to the DST series, which utilizes a dual cavity platform architecture. This design separates the primary and secondary windings into distinct chambers within the bobbin structure. The series is engineered for high isolation performance and reduced electromagnetic interference compared to traditional single-cavity designs.

Replacement Considerations

Direct substitutes include the DST-6-10 and DST-6-120 models within the same series family. These variants share identical mechanical footprints and primary winding configurations but differ in secondary voltage outputs. Cross-referencing the exact secondary current ratings is essential to ensure adequate power delivery for the specific application load.
