DZ2S03000L

Single Zener Diodes Overview

The Panasonic DZ2S03000L is a surface-mount Zener diode with a nominal voltage of 3V and a tolerance of 5%. It features a power dissipation rating of 150mW and operates within a temperature range of -40°C to +150°C. The device utilizes an SOD-523 (SSMini2 F5) package, measuring 0.8x1.6mm. Key electrical characteristics include a maximum reverse leakage current of 2µA and a Zener impedance of 80 ohms.

Single Zener Diodes Feature Summary

• Compact SOD-523 surface mount package for space-constrained designs
• High thermal stability with operation up to 150°C junction temperature
• Low leakage current specification for efficient circuit performance

Single Zener Diodes Applications

• Voltage reference circuits in portable electronics
• Transient voltage suppression in signal lines
• Biasing networks in semiconductor devices

Single Zener Diodes Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm lot traceability and RoHS compliance status prior to integration. Note that availability may be limited due to end-of-life status; validate current stock levels and lead times with suppliers before finalizing procurement plans.

Single Zener Diodes Selection Notes

Select this component when a low-voltage Zener reference is required in minimal footprint applications. Ensure the 150mW power rating suffices for the expected operating conditions. Consider the 3V nominal voltage and 5% tolerance against circuit requirements. Verify compatibility with automated pick-and-place equipment given the small SOD-523 package dimensions.

Single Zener Diodes Part Context

This part belongs to Panasonic's DZ2S series of surface-mount Zener diodes. The series offers various voltage options in the compact SOD-523 package, designed for high-density PCB layouts. It serves as a cost-effective solution for voltage regulation and protection in consumer and industrial electronics where space is at a premium.

Single Zener Diodes Replacement Considerations

Check for cross-references from other manufacturers offering identical 3V, 150mW specifications in SOD-523 packages. Verify pinout compatibility and parameter tolerances match exactly. Consider the DZ2S03300L if a different suffix indicates variant availability, though functional equivalence must be confirmed via datasheet comparison.
