E19BHPM8U12

Overview

The E19BHPM8U12 is a 19-inch, 8-unit rack height bottom-hinged panel manufactured by Hoffman Enclosures, Inc. It measures 15.0 inches in depth and features a steel construction with a light gray finish. The panel is designed for wall mounting within standard 19-inch equipment racks. It includes integral Velcro cable tiedown slots to facilitate organized cable routing and management. Thumbscrews are provided to secure the panel in the upright position during operation.

Feature Summary

• Bottom-hinged design allows the panel to pivot to 90 degrees with a positive stop for stable access
• Integral Velcro cable tiedown slots facilitate structured cable routing
• Thumbscrews secure the panel in the upright operational position

Applications

• Wall-mount installation in 19-inch equipment racks
• Punch-down interconnect platforms
• Cable management and termination stations

Procurement Notes

Verify that the application requires a bottom-hinged configuration rather than top-hinged or fixed panels. Confirm compatibility with existing 19-inch rack standards and ensure sufficient clearance for the 90-degree pivot. Check if thumbscrew hardware is included as standard. Validate that the 15-inch depth meets spatial constraints for the intended equipment layout.

Selection Notes

Select this model when a hinged solution is required for easy access to punch-down blocks or cabling. The 8-unit height accommodates specific termination needs without occupying excessive rack space. Consider the 15-inch depth relative to rear cable bend radius requirements. Ensure the environment supports the standard steel material properties unless corrosion resistance is critical.

Part Context

This component belongs to the Hoffman 19-inch rack accessory line, specifically designed for modular enclosure systems. It serves as a functional interface for telecommunications or data networking installations where frequent access to wiring is necessary. The product complements Hoffman's broader range of rack-mounted hardware solutions.

Replacement Considerations

No direct substitute part numbers are publicly confirmed for this specific bottom-hinged configuration. Alternative models may require verification of hinge orientation (top vs. bottom) and unit height compatibility.
