E25PBAM

Overview

The Hoffman E25PBAM is a steel pushbutton console enclosure designed for wall mounting. It measures 14 inches in length, 13 inches in width, and 10.13 inches in height. The unit features a light gray finish and includes twenty-five pre-drilled holes sized for 22.5mm pushbuttons. Constructed from steel, it provides IP54 protection and meets NEMA Type 12 and 13 ratings. The enclosure complies with UL 508A standards for industrial control panels.

Feature Summary

• Provides dedicated housing for twenty-five 22.5mm pushbuttons
• Constructed from steel with a light gray finish
• Offers IP54 ingress protection against dust and water jets
• Complies with NEMA Type 12 and 13 environmental standards

Applications

• Industrial machine operator consoles
• Control panel integration for automation systems
• Factory floor equipment interface stations
• Process control monitoring stations

Procurement Notes

Verify the specific ordering suffix to confirm hole configuration and material thickness. Ensure the required pushbutton diameter matches the 22.5mm specification documented for this model. Confirm compliance requirements such as UL 508A are met for the intended installation environment. Check shipping restrictions related to weight or dimensions if applicable to the destination country.

Selection Notes

Select this model when a fixed array of twenty-five controls is required within a single chassis. The 14x13 inch footprint accommodates standard industrial layouts. Verify that the NEMA 12/13 rating aligns with the environmental conditions of the installation site. Consider the wall-mount style for space-constrained applications requiring direct panel access.

Part Context

This component belongs to the Hoffman 1490 series of pushbutton enclosures. The series offers various configurations for different button counts and panel depths. The E25PBAM specifically addresses high-density control needs using standardized 22.5mm interfaces. It serves as a structural base for integrating manual input devices into larger electrical assemblies.

Replacement Considerations

Consult official Hammond Manufacturing documentation for cross-reference part numbers. Verify dimensional compatibility and hole pattern alignment before substitution. Ensure replacement units maintain equivalent IP and NEMA ratings for environmental protection.
