Product Detailed Parameters
- Description：PWR XFMR LAMINATED 50VA CHAS MT
- Series：SBE
- Mfr：SolaHD
- Package：Bulk
- Type：Laminated Core
- Voltage - Primary：-
- Voltage - Secondary (Full Load)：-
- Current - Output (Max)：-
- Primary Winding(s)：Dual, Multiple Taps
- Secondary Winding(s)：Single
- Center Tap：Yes
- Power - Max：50VA
- Mounting Type：Chassis Mount
- Termination Style：Solder, Quick Connect
- Size / Dimension：-
- Height - Seated (Max)：-
- Voltage - Isolation：-
- Weight：-
Download product information
Overview
The SolaHD E500 is a 500 VA industrial control transformer designed for bracket mounting. It features dual primary windings rated at 240 V and 480 V, providing a single secondary output of 120 V. The unit operates at 60 Hz and utilizes wire lead termination. Physical dimensions are 5.99 inches in length, 5.25 inches in width, and 5.75 inches in height. The device supports an operating temperature range from 0°C to +105°C and weighs approximately 8.64 kg.
Feature Summary
- Encapsulated construction with epoxy protection against moisture and contaminants
- IP20 touch-proof terminations for safety compliance
- Deep molded terminal barriers to reduce arcing risks
- Standardized primary coil design for flexible voltage configurations
Applications
- Industrial control panels requiring 120 V auxiliary power
- Machinery protection circuits
- Equipment isolation applications
Procurement Notes
Verify the specific datasheet version for the E500 model to confirm exact winding configuration and terminal type. Ensure the input voltage matches the dual primary rating of 240 V or 480 V. Confirm that the required output is 120 V single-phase. Check RoHS compliance status if environmental regulations apply to the installation site.
Selection Notes
Select this component when a 500 VA capacity is required for step-down applications from 240/480 V to 120 V. The encapsulated design suits environments with dust or moisture exposure. Bracket mount style is suitable for DIN rail or panel installation where space is constrained. Verify thermal requirements against the +105°C maximum operating limit.
Part Context
The E500 belongs to the SBE series of encapsulated industrial control transformers manufactured by SolaHD. This series emphasizes rugged construction and protection against industrial contaminants through epoxy encapsulation. The product line is designed for reliability in harsh environments, featuring copper windings and standardized primary coils to support various global voltage combinations.
Replacement Considerations
Direct substitutes include models within the same SBE series with matching electrical ratings. Verify physical dimensions and mounting hole patterns for compatibility. Ensure replacement units maintain the same IP20 termination safety standard and encapsulation quality.
