EA2532QA18-24.000M TR

Crystals Overview

The EA2532QA18-24.000M TR is a 24 MHz quartz crystal component manufactured by Ecliptek / Abracon. It operates within a temperature range of -40°C to +85°C and features a load capacitance of 18 pF. The unit exhibits a frequency tolerance of ±15 ppm and a stability of ±20 ppm. Its equivalent series resistance (ESR) is specified at 60 Ohms, with an excitation level of 100 uW. The device utilizes a surface-mount package measuring 3.2 mm in length, 2.5 mm in width, and 0.8 mm in height.

Crystals Feature Summary

• Provides precise timing signals through stable quartz resonance technology.
• Designed for compact integration via small surface-mount packaging.
• Ensures reliable operation across extended industrial temperature ranges.

Crystals Applications

• Embedded system clock references
• Microcontroller timing circuits
• Communication interface synchronization

Crystals Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm exact electrical tolerances and packaging configurations. Ensure compatibility with target circuit load capacitance requirements before finalizing procurement orders. Cross-reference datasheet revisions to validate current production status and compliance certifications.

Crystals Selection Notes

Select this component when a 24 MHz reference signal is required with tight frequency tolerance specifications. Evaluate the 18 pF load capacitance requirement against the host circuit design to ensure proper oscillation. Consider the -40°C to +85°C operating range suitability for the intended environmental conditions.

Crystals Part Context

This part belongs to the EA2532 series of standard crystals from Ecliptek / Abracon. The series offers various frequency options within a consistent 3.2mm x 2.5mm footprint. It serves as a fundamental passive timing element for electronic designs requiring stable clock sources without active oscillator complexity.

Crystals Replacement Considerations

Direct substitutes include other 24 MHz crystals in the same 3.2x2.5mm SMD package with matching 18pF load capacitance and similar ESR values. Verify pinout compatibility and thermal characteristics when evaluating alternative manufacturers.
