EA3250MA18-24.000M TR

Crystals Overview

EA3250MA18-24.000M TR is a quartz crystal component manufactured by Ecliptek, operating at a nominal frequency of 24 MHz. It features a load capacitance of 18 pF and a frequency tolerance of ±15 ppm. The device supports surface mount technology in a 3.2 mm x 2.5 mm package with a maximum height of 0.8 mm. It operates within a temperature range of -40°C to +85°C and has an equivalent series resistance of 40 Ohms.

Crystals Feature Summary

• Provides stable oscillation suitable for embedded communication applications
• Offers good integration compatibility with standard electronic design automation tools

Crystals Applications

• Embedded communication systems
• General-purpose timing circuits requiring 24 MHz reference

Crystals Procurement Notes

Verify the specific manufacturer designation, as sourcing data indicates dual branding under Ecliptek and Abracon. Confirm the exact package dimensions and electrical parameters against the official datasheet before finalizing procurement decisions to ensure compliance with design requirements.

Crystals Selection Notes

Select this component when a 24 MHz quartz crystal with 18 pF load capacitance is required. Ensure the application environment falls within the specified -40°C to +85°C operational temperature range. Verify that the PCB footprint accommodates the 3.2 mm x 2.5 mm SMD package size.

Crystals Part Context

This part belongs to the EA3250 series of quartz crystals. It serves as a fundamental timing element in electronic circuits, providing precise frequency references for microcontrollers and communication interfaces. The component is distinct from MEMS or oscillator ICs, relying on piezoelectric properties of quartz for stability.

Crystals Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
