EA5070PA18-25.000M TR

Crystals Overview

The EA5070PA18-25.000M TR is a surface-mount MHz crystal manufactured by Ecliptek, part of the EA5070 series. It operates at a nominal frequency of 25.000MHz with a parallel resonant mode. The component features an 18pF load capacitance and ±10ppm frequency tolerance. Housed in a standard 4-SMD, no-lead (7050) package measuring 7.0mm x 5.0mm, it supports an operating temperature range of -20°C to +70°C.

Crystals Feature Summary

• Parallel resonant operation mode for stable clock signal generation
• Standard 7050 surface-mount package design for automated assembly
• High frequency stability with ±10ppm tolerance specification

Crystals Applications

• Clock circuits in mid-to-high frequency electronic devices
• Embedded systems requiring precise timing references
• Consumer electronics utilizing surface-mount technology

Crystals Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and specific lot traceability requirements prior to procurement. Ensure storage conditions adhere to humidity sensitivity guidelines to maintain performance integrity during installation.

Crystals Selection Notes

Select this component when a 25MHz parallel resonant crystal is required within a 7050 footprint. Consider the ±10ppm tolerance and -20°C to +70°C temperature range against application needs. Evaluate load capacitance matching with oscillator circuitry to ensure accurate frequency output.

Crystals Part Context

This part belongs to the EA5070 series of quartz crystal resonators from Ecliptek. These components are designed for general-purpose timing applications where moderate stability and compact packaging are prioritized. The series offers various frequency options within the same physical envelope.

Crystals Replacement Considerations

EA5070JA18-25.000M TR
