EAM-06-101

Power Line Filter Modules Overview

The Cosel EAM-06-101 is a single-phase EMI/EMC power line filter designed for chassis mounting. It supports voltage ratings of 250 VAC and 250 VDC with a current rating of 6 A. The unit features screw termination and exhibits a leakage current of 5 µA. Certified by UL, CSA, DIN, and ENEC, it operates within a temperature range of -40°C to 85°C. The component weighs approximately 170 g and belongs to the EA series.

Power Line Filter Modules Feature Summary

• Provides single-stage electromagnetic interference suppression for single-phase circuits
• Utilizes robust chassis mount construction with screw terminal connections
• Complies with international safety standards including UL, CSA, DIN, and ENEC

Power Line Filter Modules Applications

• Industrial equipment requiring EMI filtering
• Medical devices needing certified power line protection
• Test and measurement instrumentation

Power Line Filter Modules Procurement Notes

Verify the specific part number suffix against official Cosel documentation to confirm terminal configuration and certification status. Ensure the selected variant matches the required voltage and current specifications for the target application. Cross-reference datasheets for precise mechanical dimensions and mounting hole patterns before integration.

Power Line Filter Modules Selection Notes

Select this model for applications requiring a 6 A capacity and single-phase filtering. Confirm that the chassis mount style and screw terminals align with the system's physical constraints. Verify that the operating temperature range meets environmental requirements. Check for necessary safety certifications such as UL or CSA for the intended market.

Power Line Filter Modules Part Context

This component is part of the Cosel EA series of power line filters. The series offers various current ratings and configurations for single-phase applications. The EAM-06-101 specifically addresses higher current needs compared to lower-rated models in the same family, providing standardized EMC performance for industrial and commercial power supplies.

Power Line Filter Modules Replacement Considerations

Consult official Cosel documentation for verified substitute part numbers. Do not assume cross-compatibility with other manufacturers' filters without verifying electrical parameters and mechanical fit.
