EC3620ETTTS-3.6864M TR

Oscillators Overview

The EC3620ETTTS-3.6864M TR is a standard clock oscillator manufactured by Ecliptek, operating at a nominal frequency of 3.6864 MHz. It utilizes LVCMOS output logic and requires a supply voltage of 3.3V. The component features a frequency stability of 25 ppm and includes an enable/disable function for power management. It is housed in a 4-pad surface mount ceramic package with dimensions of 3.2mm x 5.0mm x 1.3mm. The device supports tape and reel packaging for automated assembly.

Oscillators Feature Summary

• Integrates an enable/disable control function to manage power consumption states
• Utilizes LVCMOS output logic compatible with standard digital interfaces
• Constructed in a compact ceramic surface mount package for PCB integration

Oscillators Applications

• General purpose clock signal generation for digital circuits
• Timing reference sources for microcontroller systems
• Synchronization components in embedded electronic devices

Oscillators Procurement Notes

Verify the specific suffix 'TR' confirms tape and reel packaging requirements against your manufacturing equipment specifications. Ensure the 3.3V supply voltage aligns with your system design constraints. Confirm that the 4-pin SMD footprint matches your PCB layout guidelines before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a precise 3.6864 MHz timing source is required with low power capabilities. The 25 ppm stability suits applications tolerant of minor frequency variations. Consider the enable pin functionality if dynamic power saving is necessary within the target system architecture.

Oscillators Part Context

This part belongs to the EC36 series of crystal oscillators from Ecliptek. These units are designed as surface-mount solutions replacing traditional through-hole crystals. The series offers standardized frequencies and voltages for widespread industrial adoption.
