ECHO27/0.1M/IPEX/S/S/15

$12.58

Description：RF ANT 1.575GHZ PCB TRACE CAB
Series：ECHO 27
Mfr：Siretta Ltd
Package：Bag

SKU:11737a3a4868 Category: RF Antennas Brand: Siretta Ltd

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF ANT 1.575GHZ PCB TRACE CAB
Series：ECHO 27
Mfr：Siretta Ltd
Package：Bag
RF Family/Standard：Navigation
Frequency Group：UHF (1GHz ~ 2GHz)
Frequency (Center/Band)：1.575GHz
Frequency Range：-
Antenna Type：PCB Trace
Number of Bands：1
VSWR：1.5
Return Loss：-
Gain：22dBi
Features：Cable - 100mm, LNA
Termination：U.FL (UMCC), I-PEX MHF1
Ingress Protection：-
Grade：-
Qualification：-
Mounting Type：Surface Mount
Height (Max)：0.256" (6.50mm)
Applications：GPS
Power - Max：-

Download product information

ECHO27/0.1M/IPEX/S/S/15

Overview

The Siretta ECHO27/0.1M/IPEX/S/S/15 is a GPS PCB trace RF antenna operating at a center frequency of 1.575GHz. It features a gain of 22dBi and a Voltage Standing Wave Ratio (VSWR) of 1.5, with an echo loss of -7.4dB. The component utilizes a surface mount installation type and includes a 100mm cable terminated with U.FL(UMCC) or I-PEX MHF1 connectors. Designed for navigation applications, it has a maximum height of 6.50mm.

Feature Summary

Integrated Low Noise Amplifier (LNA) for signal enhancement
Compact surface-mount design suitable for space-constrained devices
Pre-attached 100mm coaxial cable with standard micro-connectors

Applications

GPS Navigation Systems
GNSS Receiver Modules
Automotive Tracking Devices

Procurement Notes

Verify the specific connector variant required, as the part number indicates compatibility with both U.FL and I-PEX MHF1 interfaces. Confirm that the integrated LNA power requirements align with the target system's voltage supply. Ensure the 100mm cable length fits within the mechanical enclosure constraints. Check current manufacturing status to confirm availability before finalizing procurement plans.

Selection Notes

Select this model when a dedicated GPS solution is needed rather than a multi-band cellular antenna. The 22dBi gain provides strong reception capabilities for satellite signals. The small form factor allows integration into portable electronics. Consider the fixed cable length during layout planning to ensure proper routing within the device chassis without strain on the connector.

Part Context

This component belongs to the ECHO 27 series by Siretta Ltd, specialized for global positioning systems. It is distinct from the ECHO 2 series, which supports multiple cellular bands including 2G through 5G. Unlike the ECHO 34 series designed for WiFi and Bluetooth, the ECHO 27 focuses exclusively on the L1 GPS frequency band for precise location tracking.
