ECLAMP8052PQTCT

$1.57

Description：CMC 2LN SMD ESD AEC-Q100
Series：EMIClamp®
Mfr：Semtech Corporation
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e9b8c487265e Category: Common Mode Chokes Brand: Semtech Corporation

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

ECLAMP8052PQTCT is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Semtech Corporation. Its product description is CMC 2LN SMD ESD AEC-Q100. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for ECLAMP8052PQTCT

Description：CMC 2LN SMD ESD AEC-Q100
Series：EMIClamp®
Mfr：Semtech Corporation
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：-
Number of Lines：2
Current Rating (Max)：-
DC Resistance (DCR) (Max)：1.8Ohm
Voltage Rating - DC：-
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：-
Approval Agency：-
Features：TVS Diode ESD Protection
Mounting Type：Surface Mount
Size / Dimension：0.075" L x 0.067" W (1.90mm x 1.70mm)
Height (Max)：0.024" (0.60mm)
Package / Case：5-UFDFN
Inductance @ Frequency：-

Common Mode Chokes datasheet and documents for ECLAMP8052PQTCT

ECLAMP8052PQTCT

Common Mode Chokes Overview

The Semtech ECLAMP8052PQTCT is a bidirectional ESD protection diode array featuring two channels. It operates within a voltage range of 5 V to 5.5 V and utilizes an SGP 5-pin surface mount package. The component provides a clamping voltage of 17 V and withstands peak pulse currents up to 6 A. It offers electrostatic discharge protection of 17 kV contact and 20 kV air gap. The device functions between -40°C and +125°C and holds AEC-Q100 qualification for automotive reliability.

Common Mode Chokes Feature Summary

Bidirectional dual-channel configuration for comprehensive line protection
AEC-Q100 qualified for automotive system integration
High electrostatic discharge immunity with low capacitance characteristics

Common Mode Chokes Applications

Automotive battery management systems
Advanced driver assistance systems (ADAS)
On-board USB chargers

Common Mode Chokes Procurement Notes

Verify the specific package designation, as sources indicate both SGP 5-pin and common mode choke classifications. Confirm AEC-Q100 status and operating temperature limits against the official datasheet. Ensure the bidirectional polarity matches the circuit requirements. Cross-reference the manufacturer part number with distributor listings to confirm current production status and availability constraints.

Common Mode Chokes Selection Notes

Select this component for applications requiring robust ESD protection on dual lines in automotive environments. The bidirectional nature suits AC or differential signal lines. Verify that the 17 V clamping voltage aligns with the downstream component's maximum ratings. The wide operating temperature range supports harsh automotive conditions. Ensure the SGP 5-pin footprint fits the PCB layout constraints.

Common Mode Chokes Part Context

This part belongs to the Semtech ECLAMP series, designed for system-level ESD and EMI protection. The series targets automotive and industrial applications requiring high reliability. The ECLAMP8052PQTCT specifically addresses dual-line protection needs with compact packaging. It complements other ECLAMP variants offering different channel counts and voltage ratings.
