EET-HC2G271BA

EET-HC2G271BA is listed in the Aluminum Electrolytic Capacitors range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is CAP ALUM 270UF 20% 400V SNAP TH. Review the specifications below when checking this part for your BOM.

Aluminum Electrolytic Capacitors specifications for EET-HC2G271BA

• Description：CAP ALUM 270UF 20% 400V SNAP TH
• Series：TS-HC
• Mfr：Panasonic Electronic Components
• Package：Bulk
• Capacitance：270 µF
• Tolerance：±20%
• Voltage - Rated：400 V
• ESR (Equivalent Series Resistance)：675mOhm @ 120Hz
• Lifetime @ Temp.：2000 Hrs @ 105°C
• Operating Temperature：-25°C ~ 105°C
• Polarization：Polar
• Ratings：-
• Applications：General Purpose
• Ripple Current @ Low Frequency：1.22 A @ 120 Hz
• Ripple Current @ High Frequency：1.71 A @ 10 kHz
• Lead Spacing：0.394" (10.00mm)
• Size / Dimension：0.866" Dia (22.00mm)
• Height - Seated (Max)：2.047" (52.00mm)
• Surface Mount Land Size：-
• Mounting Type：Through Hole
• Package / Case：Radial, Can - Snap-In

Aluminum Electrolytic Capacitors datasheet and documents for EET-HC2G271BA
