ELC-06D180E

Fixed Inductors Overview

The Panasonic ELC-06D180E is a leaded power inductor from the ELC-06D series, designed for PCB mounting. It features an unshielded wirewound construction with a ferrite core and radial termination style. The component provides an inductance of 18 µH with a tolerance of 20%. It supports a maximum DC current of 1.25 A and has a maximum DC resistance of 65 mOhms. The physical dimensions are 6.7 mm in diameter by 10.5 mm in height, with a lead spacing of 3 mm and lead diameter of 0.65 mm. It operates within a temperature range of -40°C to +105°C and is tested at 10 kHz.

Fixed Inductors Feature Summary

• Radial leaded construction suitable for through-hole PCB mounting
• Unshielded wirewound design utilizing a ferrite core
• High current handling capability up to 1.25 A
• Low DC resistance of 65 mOhms for efficient power delivery

Fixed Inductors Applications

• Power supply filtering circuits
• Choke applications in electronic equipment
• General-purpose power electronics

Fixed Inductors Procurement Notes

Verify the specific suffix (e.g., 'E') against official Panasonic documentation to confirm exact electrical tolerances and packaging specifications. Confirm RoHS compliance status and end-of-life or obsolescence notices directly with the manufacturer before procurement planning.

Fixed Inductors Selection Notes

Select this component when a radial leaded form factor is required for high-current power applications. Ensure the circuit design accommodates the unshielded magnetic field and verify that the 1.25 A saturation current meets the peak load requirements of the target application.

Fixed Inductors Part Context

This part belongs to the Panasonic ELC-06D series of fixed power inductors. The series offers various inductance values in a consistent radial package, providing designers with standardized options for power stage filtering and energy storage in compact electronic designs.

Fixed Inductors Replacement Considerations

Cross-reference with other Panasonic ELC-06D variants for different inductance values. Verify mechanical footprint compatibility and electrical parameters with equivalent radial power inductors from other manufacturers if sourcing alternatives.
