ELC-3FN6R8N is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is FIXED IND 6.8UH 620MA 360MOHM SM. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for ELC-3FN6R8N
- Description：FIXED IND 6.8UH 620MA 360MOHM SM
- Series：N
- Mfr：Panasonic Electronic Components
- Package：Tape & Reel (TR),Cut Tape (CT)
- Type：-
- Material - Core：-
- Inductance：6.8 µH
- Tolerance：±30%
- Current Rating (Amps)：620 mA
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：360mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.126" L x 0.126" W (3.20mm x 3.20mm)
- Height - Seated (Max)：0.047" (1.20mm)
Fixed Inductors datasheet and documents for ELC-3FN6R8N
Fixed Inductors Overview
The Panasonic ELC-3FN6R8N is a fixed surface-mount power inductor with an inductance of 6.8 µH and a tolerance of ±30%. It features an unshielded construction designed for general-purpose filtering applications. The component has a maximum DC resistance of 360 mOhm and a current rating of 620 mA. This part belongs to the ELC-3FN series, which utilizes nonstandard packaging dimensions suitable for compact electronic designs.
Fixed Inductors Feature Summary
- Unshielded magnetic structure for reduced size
- Fixed inductance value for stable circuit performance
- Surface-mount technology for automated assembly
Fixed Inductors Applications
- General-purpose signal filtering
- Power supply input/output stages
- Compact consumer electronics circuits
Fixed Inductors Procurement Notes
This component is classified as discontinued or not for new designs by the manufacturer. Procurement should focus on existing stock from authorized distributors rather than direct manufacturing orders. Verify lot dates carefully due to potential age-related degradation. Ensure compatibility with legacy systems where this specific inductance and form factor are required.
Fixed Inductors Selection Notes
Engineers replacing this part must consider its discontinuation status when designing new products. Alternative components with similar inductance and current ratings should be evaluated for pin compatibility and thermal performance. The unshielded nature requires careful PCB layout to minimize electromagnetic interference with nearby sensitive traces compared to shielded alternatives.
Fixed Inductors Part Context
The ELC-3FN6R8N is part of Panasonic's broader ELC series of passive components. This series typically offers various inductance values within a standardized footprint family. The specific model provides a mid-range inductance value suitable for low-power applications, distinguishing it from higher-current variants in the same product line.
Fixed Inductors Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Designers should consult Panasonic directly for cross-reference recommendations or select third-party equivalents based on electrical specifications.
