ELJ-ND1R0KF

Fixed Inductors Overview

The ELJ-ND1R0KF is a fixed surface-mount wirewound inductor from Panasonic Electronic Components, housed in an 0805 (2012 Metric) package. It features a nominal inductance of 1 µH with a tolerance of ±10%. The component has a maximum DC resistance of 3.88 Ohms and a rated current of 120 mA. Designed for high-frequency applications, it utilizes a non-magnetic core to minimize interference. The device is lead-free and RoHS compliant, suitable for reflow or flow soldering processes.

Fixed Inductors Feature Summary

• High-frequency capability enabled by a non-magnetic core design
• Compatible with standard reflow and flow soldering manufacturing processes

Fixed Inductors Applications

• RF circuit filtering
• Signal processing in communication devices
• Power supply output chokes

Fixed Inductors Procurement Notes

Verify the specific ordering suffix to ensure correct tolerance and packaging specifications. Confirm that the selected variant matches the required inductance value and current rating for the target application. Check for any recent product discontinuation notices or alternative series recommendations from the manufacturer before finalizing procurement plans.

Fixed Inductors Selection Notes

Select this component based on its 1 µH inductance and 120 mA current handling capacity within the 0805 footprint. Ensure the design accommodates the 3.88 Ohm DC resistance. Verify compatibility with the intended operating frequency range and confirm that the non-magnetic core characteristics align with the electromagnetic interference requirements of the system.

Fixed Inductors Part Context

This part belongs to the ELJ-ND series of chip inductors manufactured by Panasonic Electronic Components. The series offers a wide lineup of case sizes ranging from 1005 to 3225 metrics. These components are designed for general-purpose electronic equipment requiring stable inductance values in compact surface-mount configurations.

Fixed Inductors Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official manufacturer resources for potential cross-references or updated series replacements.
