ELL-CTV221M

$1.33

Description：FIXED IND 220UH 840MA 310MOHM SM
Series：V
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:a05f875c6805 Category: Fixed Inductors Brand: Panasonic Electronic Components

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

ELL-CTV221M is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Panasonic Electronic Components. Its product description is FIXED IND 220UH 840MA 310MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for ELL-CTV221M

Description：FIXED IND 220UH 840MA 310MOHM SM
Series：V
Mfr：Panasonic Electronic Components
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Drum Core, Wirewound
Material - Core：Ferrite
Inductance：220 µH
Tolerance：±20%
Current Rating (Amps)：840 mA
Current - Saturation (Isat)：-
Shielding：Shielded
DC Resistance (DCR)：310mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.472" L x 0.472" W (12.00mm x 12.00mm)
Height - Seated (Max)：0.177" (4.50mm)
Features：-

Fixed Inductors datasheet and documents for ELL-CTV221M

ELL-CTV221M

Fixed Inductors Overview

The ELL-CTV221M is a shielded drum core, wirewound fixed inductor manufactured by Panasonic Industry. It features an inductance of 220 µH with a tolerance of ±20%. The component supports a maximum DC current of 840 mA and exhibits a maximum DC resistance of 310 mΩ. Designed for surface-mount applications, it utilizes nonstandard terminals to facilitate PCB integration. This power choke belongs to the ELL-CTV series, offering compact dimensions suitable for space-constrained electronic designs requiring reliable magnetic shielding.
