EMIF02-01OABRY is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists STMicroelectronics. Its product description is CMC 2LN ESD AEC-Q101. Review the specifications below when checking this part for your BOM.
Common Mode Chokes specifications for EMIF02-01OABRY
- Description：CMC 2LN ESD AEC-Q101
- Series：EMIF
- Mfr：STMicroelectronics
- Package：Tape & Reel (TR),Cut Tape (CT)
- Filter Type：-
- Number of Lines：2
- Current Rating (Max)：-
- DC Resistance (DCR) (Max)：-
- Voltage Rating - DC：-
- Voltage Rating - AC：-
- Operating Temperature：-40°C ~ 125°C
- Ratings：-
- Approval Agency：-
- Features：TVS Diode ESD Protection
- Mounting Type：-
- Size / Dimension：0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height (Max)：0.035" (0.90mm)
- Package / Case：6-VDFN
- Inductance @ Frequency：-
- Impedance @ Frequency：-
Common Mode Chokes datasheet and documents for EMIF02-01OABRY
Common Mode Chokes Overview
The EMIF02-01OABRY is an integrated low-pass filter with electrostatic discharge (ESD) protection designed for BroadR-Reach interfaces. It suppresses electromagnetic interference (EMI) and radio frequency interference (RFI) in automotive applications. The component features a 3x3 QFN package with wettable flanks to ensure Automated Optical Inspection (AOI) compatibility during printed circuit board assembly. It provides attenuation profiles compliant with BroadR-Reach specifications across operating temperatures from -40 °C to 125 °C.
Common Mode Chokes Feature Summary
- Integrated ESD protection and low-pass filtering for BroadR-Reach interfaces
- Suppression of parasitic common and differential signals
- Compliance with ISO10605 and ISO7637-3 standards
- Surface-mount package with wettable flanks for AOI compatibility
Common Mode Chokes Applications
- Automotive BroadR-Reach Ethernet interfaces
- Medium-dependent interface (MDI) boards
- Electronic circuits requiring EMI/RFI suppression
Common Mode Chokes Procurement Notes
Verify the specific suffix 'OABRY' to confirm the 3x3 QFN package with wettable flanks configuration. Ensure the procurement matches the BroadR-Reach application requirements. Confirm RoHS compliance status as documented. Check for any product termination notifications or lifecycle changes associated with this specific part number before finalizing orders.
Common Mode Chokes Selection Notes
Select this component when designing BroadR-Reach systems requiring integrated ESD protection and EMI filtering. The choice is driven by the need for AOI-compatible packaging and compliance with automotive temperature ranges. Consider the STEVAL-OET002V1 evaluation board for design verification. Ensure the interface supports two unshielded twisted pair wires.
Common Mode Chokes Part Context
This component belongs to the EMIF02 family, which includes similar parts like the EMIF02-02OABRY. These devices are highly integrated solutions aimed at suppressing noise in automotive BroadR-Reach interfaces. The family ensures signal integrity while protecting against electrical disturbances in harsh automotive environments.
Common Mode Chokes Replacement Considerations
The EMIF02-02OABRY is a related part within the same family. Verify if the alternative part meets the specific pinout and performance requirements for the BroadR-Reach interface. Consult official documentation to confirm functional equivalence.
