EP3SL150F780C4LG

Field Programmable Gate Array Overview

The EP3SL150F780C4LG is a Stratix III Field Programmable Gate Array (FPGA) manufactured by Altera. It features 2700 Adaptive Logic Modules (ALMs) and supports up to 488 I/O pins within a 780-ball FineLine BGA package. The device operates at a core voltage of 1.1 V and includes 2.57 Mbit of embedded memory, comprising 422 kbit of embedded block RAM. It is designed for commercial temperature ranges from 0°C to +70°C. The component complies with RoHS standards and carries a Moisture Sensitivity Level (MSL) rating of 3.

Field Programmable Gate Array Feature Summary

• Supports high-density logic implementation through 2700 ALMs for complex digital designs
• Integrates substantial on-chip memory resources including embedded block RAM for data buffering
• Provides extensive external connectivity via 488 available I/O pins
• Compatible with standard surface-mount assembly processes in FBGA-780 packaging

Field Programmable Gate Array Applications

• High-performance industrial control systems requiring robust programmable logic
• Telecommunications infrastructure equipment utilizing multiple interface protocols
• Medical imaging devices needing flexible signal processing capabilities
• Test and measurement instrumentation requiring reconfigurable hardware architectures

Field Programmable Gate Array Procurement Notes

Verify the complete part number including the 'LG' suffix against official manufacturer documentation to ensure correct configuration. Confirm RoHS compliance status and MSL handling requirements prior to storage. Check for any specific pinout revisions or known issues lists associated with this specific batch code before finalizing procurement plans.

Field Programmable Gate Array Selection Notes

Select this component when design requirements exceed Cyclone capabilities but do not necessitate Stratix IV performance levels. Evaluate the 2.57 Mbit memory capacity against algorithm buffer needs. Ensure PCB layout tools support the 780-ball FBGA footprint and thermal dissipation requirements for the 1.1 V core voltage operation.

Field Programmable Gate Array Part Context

This device belongs to the Stratix III family, representing a mid-range FPGA solution from Altera. It bridges the gap between lower-density Cyclone devices and higher-end Stratix IV series. The EP3SL150 variant offers a balanced mix of logic density and I/O flexibility suitable for general-purpose high-performance applications.

Field Programmable Gate Array Replacement Considerations

Direct functional equivalents are limited due to architectural differences. Consider Stratix IV variants for upward migration if pin compatibility allows. Verify that alternative components support similar memory densities and I/O counts without requiring significant schematic redesign.
