EP3SL70F780C3G

Field Programmable Gate Array Overview

The EP3SL70F780C3G is a Stratix III L Field Programmable Gate Array (FPGA) manufactured by Altera. It features 2,700 Logic Array Blocks (LABs), providing 67,500 logic elements for complex digital designs. The device integrates 2.57 Mbits of embedded memory and supports up to 488 I/O pins. It operates within a supply voltage range of 1.1V to 1.15V and functions reliably across an industrial temperature range of -40°C to +85°C. The component is housed in a 780-ball Fine-Pitch Ball Grid Array (FCBGA) package with dimensions of 29x29 mm, designed for surface-mount installation.

Field Programmable Gate Array Feature Summary

• Stratix III L architecture with 2,700 LABs and 67,500 logic elements
• Integrated 2.57 Mbits of embedded memory for data storage and processing
• Supports 488 user I/O pins for high-density connectivity
• Industrial temperature rating (-40°C to +85°C) for robust operation

Field Programmable Gate Array Applications

• High-performance telecommunications infrastructure equipment
• Industrial automation and control systems requiring wide temperature tolerance
• Test and measurement instrumentation
• Medical imaging system signal processing

Field Programmable Gate Array Procurement Notes

Verify the specific suffix 'C3G' against official manufacturer documentation to confirm availability and exact electrical characteristics, as datasheet references often list variants like C4 or I3G. Confirm RoHS compliance status and moisture sensitivity level (MSL 3) prior to ordering. Check for obsolescence notices or product change notifications (PCN) from Altera/Intel to ensure long-term supply chain stability for production runs.

Field Programmable Gate Array Selection Notes

Select this model when a balance of moderate logic density and low power consumption is required compared to standard Stratix III devices. Ensure the design utilizes the 1.1V core voltage domain correctly. Verify that the 780-pin FCBGA footprint matches the PCB layout constraints. Compare against Cyclone III series if lower cost is prioritized over performance, or Stratix IV if higher bandwidth is needed.

Field Programmable Gate Array Part Context

This component belongs to the Stratix III family, specifically the 'L' (Low Power) sub-series, which offers reduced power consumption while maintaining high performance. It serves as a mid-range solution in Altera's portfolio, bridging the gap between smaller Cyclone devices and larger Stratix families. The EP3SL70 variant provides a scalable platform for designs requiring significant logic resources without the complexity of top-tier high-end FPGAs.

Field Programmable Gate Array Replacement Considerations

Direct pin-to-pin replacements are not publicly confirmed for this specific part number. Consider the EP3SL70F780I3G for extended temperature ranges or the EP3SL70F780C4 for commercial grade alternatives, though verification of electrical compatibility and software tool support is mandatory before substitution.
