EP4SE230F29C4

Field Programmable Gate Array Overview

The Altera EP4SE230F29C4 is a Stratix IV E Field Programmable Gate Array (FPGA) manufactured using 40-nm technology. It features 228,000 logic elements and 17,544 adaptive logic modules (ALMs). The device includes 22.04 Mbit of embedded memory and supports up to 488 I/O pins. It operates within a junction temperature range of -40°C to +100°C and utilizes a 780-pin FBGA package with a 29x29 mm footprint.

Field Programmable Gate Array Feature Summary

• Stratix IV E architecture with 228,000 LEs and 17,544 ALMs
• 22.04 Mbit embedded memory capacity
• Supports up to 488 I/O connections
• Operates at core voltage of 0.87V to 0.93V

Field Programmable Gate Array Applications

• High-performance digital signal processing
• Industrial automation control systems
• Telecommunications infrastructure equipment

Field Programmable Gate Array Procurement Notes

Verify component authenticity through authorized distributors or official Altera channels. Confirm RoHS compliance status and moisture sensitivity level (MSL 3) prior to soldering. Check for End-of-Life (EOL) notices or Product Change Notifications (PCN) as availability may be restricted. Ensure packaging integrity matches standard tray specifications for surface-mount assembly.

Field Programmable Gate Array Selection Notes

Select this model when requiring moderate logic density with low power consumption compared to GX/GT variants. Verify that the 780-pin FBGA package fits the PCB layout constraints. Ensure design tools support the specific speed grade C4 for timing closure. Compare against EP4SE230F29I4G if industrial temperature ranges are required instead of commercial/extended options.

Field Programmable Gate Array Part Context

This component belongs to the Stratix IV E family, designed for cost-sensitive applications requiring high performance. It shares architectural similarities with other EP4SE230 variants but differs in package type and operating temperature specifications. The 'C4' suffix indicates a specific speed grade and commercial/extended temperature range configuration within the Stratix IV portfolio.

Field Programmable Gate Array Replacement Considerations

Direct pin-compatible replacements include EP4SE230F29I4G for extended temperature ranges. Cross-family migration to Cyclone V or Arria V requires retiming and resource verification. Consult Altera documentation for specific cross-reference guides regarding logic block compatibility.
