EP4SGX230FF35C4

Field Programmable Gate Array Overview

The EP4SGX230FF35C4 is a Stratix IV GX Field Programmable Gate Array manufactured by Altera. It features 228,000 logic elements and 91,200 adaptive logic modules within a 1152-ball FBGA package. The device includes 16 transceivers supporting data rates from 600 Mb/s to 8.5 Gb/s and provides 564 I/Os. Embedded memory capacity is 16.73 Mbit. Operating voltage is specified at 900 mV, with an operating temperature range of -40°C to +85°C for the industrial grade variant.

Field Programmable Gate Array Feature Summary

• Stratix IV GX architecture with 228,000 LEs and 16 high-speed transceivers
• 1152-ball FBGA package with 564 I/Os
• Transceiver data rates up to 8.5 Gb/s
• Industrial temperature range (-40°C to +85°C)

Field Programmable Gate Array Applications

• High-speed serial communications
• Network infrastructure equipment
• Test and measurement instrumentation

Field Programmable Gate Array Procurement Notes

Verify component authenticity through authorized channels due to potential availability constraints. Confirm RoHS compliance status and moisture sensitivity level (MSL 3) prior to handling. Check for obsolescence notices as this series may have limited production support compared to newer generations.

Field Programmable Gate Array Selection Notes

Select this model for designs requiring high-density logic combined with multi-gigabit transceivers. Ensure PCB layout supports the 1152-ball FBGA footprint. Verify that the 900 mV core voltage supply meets the specific power delivery requirements for the Stratix IV GX family.

Field Programmable Gate Array Part Context

This part belongs to the Altera Stratix IV GX family, designed for applications demanding high bandwidth and complex logic processing. It utilizes TSMC's 40-nm technology. The 'GX' designation indicates the inclusion of high-speed serial transceivers, distinguishing it from the GT or E variants in the same family.

Field Programmable Gate Array Replacement Considerations

Publicly confirmed direct substitute part numbers are not available in the provided source material. Consider consulting official replacement guides for newer Intel FPGA families if discontinuation is confirmed.
