EQY-6-283+

$25.86

Description：RF FILTER LOW PASS 28GHZ 6TDFN
Series：-
Mfr：Mini-Circuits
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:5136d0bf45bd Category: RF Filters Brand: Mini-Circuits

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：RF FILTER LOW PASS 28GHZ 6TDFN
Series：-
Mfr：Mini-Circuits
Package：Tape & Reel (TR),Cut Tape (CT)
Frequency：28GHz (Cutoff)
Bandwidth：-
Filter Type：Low Pass
Ripple：-
Insertion Loss：6.9dB
Mounting Type：Surface Mount
Package / Case：6-TDFN Exposed Pad
Size / Dimension：0.079" L x 0.079" W (2.00mm x 2.00mm)
Height (Max)：0.041" (1.05mm)

Download product information

EQY-6-283+

Overview

The EQY-6-283+ is a fixed slope gain equalizer MMIC from Mini-Circuits, operating from DC to 28 GHz. It provides a nominal attenuation of 6 dB with a slope characteristic. The device utilizes an absorptive design for stable performance across its wide bandwidth. It is housed in a compact 6-terminal TDFN exposed pad package suitable for surface mount assembly. The component supports operation within a temperature range of -55°C to +105°C.

Feature Summary

Absorptive equalizer topology ensures stability without oscillation risks
Wideband frequency coverage from DC to 28 GHz
Fixed 6 dB attenuation with defined slope characteristic
Compact surface-mount TDFN package for high-density integration

Applications

Millimeter-wave communication systems
Test and measurement instrumentation signal conditioning
Satellite communication front-end modules
Radar system signal processing chains

Procurement Notes

Verify the specific datasheet version for precise S-parameter data and thermal resistance values. Confirm package compatibility with PCB footprint designs. Ensure supply chain sources provide genuine Mini-Circuits components with proper RoHS compliance documentation. Check lead times as availability may vary by region.

Selection Notes

Select this component when a fixed 6 dB slope correction is required up to 28 GHz. Compare against reflective equalizers if low insertion loss at DC is critical, as this is an absorptive type. Consider the TDFN package size constraints and thermal management requirements for high-power applications.

Part Context

This part belongs to the EQY series of gain equalizers from Mini-Circuits. These components are designed to compensate for frequency-dependent gain variations in RF chains. The series offers various attenuation levels and slope characteristics to suit different system requirements.

Replacement Considerations

Direct substitutes include other Mini-Circuits fixed slope equalizers such as the EQY-3-283+ or EQY-9-283+ depending on the required attenuation level. Verify electrical specifications and pinout compatibility before substitution.
