ES1-F05

Power Line Filter Modules Overview

The DIT ES1-F05 is a single-phase EMC/EMI line filter module designed for power line noise suppression. It supports a rated voltage of 250V AC or DC and handles a rated current of 5A. The unit operates within a frequency range of 50 to 60Hz and features a single-stage filtering architecture. It utilizes quick connect terminals for installation and is rated for an operating temperature range of -25°C to +85°C, including a maximum temperature rise of 30°C.

Power Line Filter Modules Feature Summary

• Single-stage EMI/EMC noise filtration for single-phase applications
• Quick connect terminal interface for simplified mounting
• Chassis mount design for industrial integration

Power Line Filter Modules Applications

• Power supply input filtering
• Industrial equipment noise suppression
• Electronic device EMC compliance

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from DIT (Dongil Electronics) to confirm exact dimensional tolerances and terminal specifications. Ensure the application environment stays within the -25°C to +85°C operating range. Confirm that the 5A current rating aligns with the load requirements to prevent overheating beyond the specified 30°C temperature rise limit.

Power Line Filter Modules Selection Notes

Select this component when single-phase noise reduction is required for circuits operating at 250VAC/VDC. The 5A current capacity suits moderate power loads. Verify that the quick connect terminal style matches the existing wiring harness or PCB footprint. Consider the chassis mount form factor for space-constrained enclosures requiring robust mechanical stability.

Power Line Filter Modules Part Context

This model belongs to the ES1 series of power line filters manufactured by DIT. The series provides standardized EMC solutions for various current ratings. The ES1-F05 specifically addresses the 5A requirement tier within this product family, offering a compact solution for single-phase AC/DC line filtering in electronic systems.

Power Line Filter Modules Replacement Considerations

Consult official DIT documentation for direct cross-references. No public substitute part numbers are confirmed in the available source material.
