ES1-F08

Power Line Filter Modules Overview

The DIT ES1-F08 is a single-phase EMI/EMC line filter module designed for chassis mounting. It operates at a rated voltage of 250V AC and supports a continuous current of 8A within the 50-60Hz frequency range. The component utilizes a single-stage filtering architecture to suppress electromagnetic interference on power lines. Electrical connections are established via quick connect terminals, facilitating integration into electronic equipment requiring noise reduction.

Power Line Filter Modules Feature Summary

• Single-stage EMI/EMC filtering architecture
• Chassis mount mechanical design
• Quick connect terminal interface

Power Line Filter Modules Applications

• Power supply input stages
• Electronic equipment noise suppression
• Industrial control systems

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version from Dong Il Technology (DIT) to confirm pinout compatibility and thermal ratings. Ensure the application environment matches the 250V AC and 8A DC/AC specifications. Confirm that the quick connect terminal style aligns with existing harness designs before procurement.

Power Line Filter Modules Selection Notes

Select this component when an 8A capacity is required for single-phase applications. The chassis mount form factor suits enclosed equipment installations. Verify that the single-stage attenuation meets the specific EMC standards required by the target market or industry regulation.

Power Line Filter Modules Part Context

The ES1-F08 belongs to the ES1 series of EMI/EMC filters manufactured by Dong Il Technology. This series includes variants such as the ES1-F05 and ES1-F10, differentiated primarily by their rated current capacities while maintaining similar voltage ratings and structural designs for consistent integration across product lines.

Power Line Filter Modules Replacement Considerations

Cross-reference with ES1-F05 or ES1-F10 if current requirements differ. Verify that alternative components maintain the same 250V rating and quick connect terminal configuration to ensure mechanical and electrical compatibility without redesigning the PCB or wiring harness.
