ES1-F15

Power Line Filter Modules Overview

The ES1-F15 is a single-phase EMC/EMI line filter module manufactured by DIT. It is rated for 15 A current and supports voltages up to 250 VAC/VDC at 50–60 Hz. The unit features a chassis-mount design with epoxy potting for environmental protection. It provides significant attenuation of high-voltage pulses and offers effective shielding via its metal enclosure. The filter ensures excellent performance in both differential-mode and common-mode noise suppression, complying with CE, SEMKO, and ENEC safety standards.

Power Line Filter Modules Feature Summary

• Provides effective differential-mode and common-mode filtering characteristics
• Features a metal enclosure for superior shielding performance
• Offers significant attenuation against high-voltage pulses
• Utilizes epoxy potting for robust environmental protection

Power Line Filter Modules Applications

• Industrial equipment such as CNC machines
• Inverters and converters
• Telecommunications equipment
• Factory automation (FA) devices
• Elevator systems

Power Line Filter Modules Procurement Notes

Verify the specific mounting configuration required for your chassis installation before ordering. Confirm that the input voltage and frequency ratings align with your system's electrical specifications. Ensure the 15 A current capacity meets the peak load requirements of the connected equipment. Check for compliance with regional safety certifications if applicable to your deployment environment.

Power Line Filter Modules Selection Notes

Select this component when robust EMI/EMC suppression is required for single-phase AC power lines in industrial settings. The chassis-mount form factor is suitable for integration into larger control panels or enclosures. Consider the epoxy-potted construction for applications requiring resistance to moisture or dust. Ensure adequate clearance for heat dissipation despite the low power loss typical of passive filters.

Power Line Filter Modules Part Context

DIT manufactures a range of power line filters designed for industrial environments. The ES1-F15 belongs to a series of single-phase filters characterized by high current handling and strong pulse attenuation. These components are engineered to protect sensitive electronics from conducted interference while maintaining signal integrity in noisy power networks.

Power Line Filter Modules Replacement Considerations

No verified public substitute part numbers are available for this specific model.
