ES1-F20

Power Line Filter Modules Overview

The ES1-F20 is a single-phase EMC/EMI line filter module manufactured by DIT. It is rated for 20 A current and 250 VAC voltage, operating at 50 to 60 Hz frequencies. The component utilizes a quick connect interface for chassis mounting. It functions as a single-stage noise suppression unit designed to mitigate electromagnetic interference in AC power lines.

Power Line Filter Modules Feature Summary

• Provides single-stage EMI/EMC noise filtration for single-phase AC power applications
• Features quick connect terminals for simplified chassis integration
• Designed for operation within standard industrial temperature ranges

Power Line Filter Modules Applications

• Single-phase AC power input filtering
• Chassis-mounted electronic equipment noise suppression
• Industrial control system power line protection

Power Line Filter Modules Procurement Notes

Verify the specific manufacturer designation, as sources indicate potential association with Dong Il Technology or SME. Confirm the exact terminal configuration and certification status (e.g., K56571698) against the official datasheet before procurement. Ensure the component matches the required 20A/250V specifications for the target application.

Power Line Filter Modules Selection Notes

Select this component for single-phase applications requiring 20 A capacity and 250 VAC rating. Ensure the design accommodates chassis mounting and quick connect interfaces. Verify that the single-stage filtration meets the specific EMI/EMC attenuation requirements of the system without necessitating multi-stage solutions.

Power Line Filter Modules Part Context

The ES1-F20 belongs to the ES1 series of EMI/EMC filters from DIT. This series includes variations such as the ES1-T30 for 30 A applications. The series offers multiple X and Y capacitor value options to achieve various regulatory approvals while maintaining consistent form factors for single-phase power line filtering.

Power Line Filter Modules Replacement Considerations

The ES1-T30 serves as a higher current alternative within the same ES1 series. Verify compatibility regarding physical dimensions and terminal types when substituting. No other direct cross-model substitutes are confirmed in available documentation.
