ES1-T05

Power Line Filter Modules Overview

The DIT ES1-T05 is a single-phase EMC/EMI line filter module designed for AC power line noise suppression. It operates at a rated current of 5 A and supports voltages up to 250 VAC within the 50–60 Hz frequency range. The component utilizes a single-stage filtering topology to attenuate electromagnetic interference. Electrical termination is provided via M4 threaded terminal blocks, ensuring secure mechanical connection for industrial wiring applications.

Power Line Filter Modules Feature Summary

• Single-phase EMI/EMC filtering capability
• Threaded terminal block interface for secure mounting

Power Line Filter Modules Applications

• Industrial control systems
• Power supply input stages
• Electronic equipment noise suppression

Power Line Filter Modules Procurement Notes

Verify the specific datasheet version with the manufacturer or authorized distributor before procurement. Confirm that the M4 threaded terminal configuration matches your panel design requirements. Ensure the 5 A current rating and 250 VAC voltage limit are sufficient for your target circuit load conditions to prevent component failure.

Power Line Filter Modules Selection Notes

Select this model when single-phase AC line filtering is required for low-current applications up to 5 A. The threaded terminal design offers robust mechanical stability compared to screw-terminal alternatives. Consider thermal management requirements if the operating environment exceeds standard ambient temperatures.

Power Line Filter Modules Part Context

This component belongs to the DIT series of power line filters. These modules are engineered for integration into AC power entry points. The ES1-T05 variant specifically addresses common-mode and differential-mode noise in single-phase circuits using passive filtering elements housed in a compact form factor suitable for DIN-rail or panel mounting.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Verify compatibility by matching electrical ratings (5 A, 250 VAC) and physical interface dimensions (M4 terminals) with alternative suppliers.
