ES1-T08

Power Line Filter Modules Overview

The DIT ES1-T08 is a single-phase EMC/EMI line filter module designed for power line noise suppression. It supports a rated current of 8 A and operates at voltages up to 250 VAC or 250 VDC. The unit functions within a frequency range of 50 to 60 Hz and utilizes a single-stage filtering architecture. Mechanical mounting is achieved via threaded posts with an M4 specification, facilitating secure chassis installation in general-purpose electronic applications requiring reliable signal integrity.

Power Line Filter Modules Feature Summary

• Provides remarkable attenuation for high voltage impulses
• Ensures good shield effect through the use of a metal case
• Delivers excellent filtering characteristics for both conducted emissions

Power Line Filter Modules Applications

• General purpose electronic equipment
• Chassis mounted systems requiring EMI suppression
• Single phase power line noise reduction

Power Line Filter Modules Procurement Notes

Verify the specific ordering suffix against the manufacturer's official documentation to ensure correct terminal configuration and mounting style. Confirm that the M4 threaded post requirement aligns with your chassis design. Cross-reference the 8 A current rating and 250 VAC/VDC limits with your system's electrical specifications to prevent component failure under load conditions.

Power Line Filter Modules Selection Notes

Select this component when a slim, lightweight single-phase filter is required for limited internal space. Ensure the application environment accommodates the metal case construction for optimal shielding. Verify that the M4 mounting interface matches existing hardware. This model is suitable for general-purpose use where standard 50-60 Hz operation and moderate impulse attenuation are sufficient.

Power Line Filter Modules Part Context

The ES1-T08 belongs to the DIT ES1 Series, which comprises single-phase chassis mount EMC/EMI filters. This series is characterized by slim and lightweight designs intended for integration into devices with constrained internal volumes. The T08 variant specifically denotes the 8 A current rating and threaded post termination style within the broader product family.

Power Line Filter Modules Replacement Considerations

Consult the official DIT datasheet for direct substitute part numbers within the ES1 series, such as variants with different current ratings like ES1-F08 or ES1-T10. Ensure any replacement maintains the same M4 mounting interface and voltage/current specifications to guarantee mechanical and electrical compatibility.
