ES1-T20

Power Line Filter Modules Overview

The ES1-T20 is a power line filter module manufactured by DIT (Dongil Giyun). It is designed for chassis mounting with M4 threaded posts. The component supports a current rating of 20A and operates at voltages up to 250VAC/VDC. It complies with ROHS3 standards and carries an EAR99 classification.

Power Line Filter Modules Feature Summary

• Chassis mount design with screw-type M4 posts
• Power line noise filtering capability
• ROHS3 compliant construction

Power Line Filter Modules Applications

• Industrial equipment power input stages
• Electronic enclosures requiring EMI suppression
• Chassis-mounted power distribution units

Power Line Filter Modules Procurement Notes

Verify the specific datasheet from Dongil Giyun for detailed electrical characteristics and mechanical drawings. Confirm that the M4 post configuration matches your chassis panel thickness and hole spacing requirements before ordering.

Power Line Filter Modules Selection Notes

Select this model when a robust, chassis-mountable solution is required for high-current applications up to 20A. Ensure the operating voltage does not exceed 250VAC or VDC. Consider the physical dimensions and mounting hardware compatibility with your system enclosure.

Power Line Filter Modules Part Context

This part belongs to the ES1 series of noise filters from Dongil Giyun. These components are engineered for electromagnetic interference suppression in AC/DC power lines. The T20 suffix typically denotes the specific current and voltage rating variant within the product family.

Power Line Filter Modules Replacement Considerations

No direct public substitute part numbers are confirmed in available documentation. Verify pinout and mounting dimensions if considering alternative brands.
