ESD-FPD-34

$6.71

Description：FERRITE CORE CLIP 48.3 X 2MM
Series：ESD-FPD
Mfr：KEMET
Package：Bulk

SKU:0713aa04f413 Category: Cable Ferrites Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：FERRITE CORE CLIP 48.3 X 2MM
Series：ESD-FPD
Mfr：KEMET
Package：Bulk
Type：Flat
Design：Clip Together (Order Qty 1=1 Assembly)
Impedance @ Frequency：-
Material：-
Inner Dimension：1.901" W x 0.078" H (48.30mm x 2.00mm)
Outer Dimension：2.362" W x 0.393" H (60.00mm x 10.00mm)
Ratings：-
Mounting Type：Free Hanging
Length：0.500" (12.70mm)

Download product information

ESD-FPD-34

Overview

The ESD-FPD-34 is a split-core flat cable ferrite manufactured by KEMET. It features an inner dimension of 48.30mm width and 2.00mm height, with outer dimensions of 60.00mm width and 10.00mm height. The component is designed for clip-together assembly, where one unit constitutes a single assembly. It serves as a specialized electromagnetic interference (EMI) protection device for flat cables.

Feature Summary

Split-core design allows installation on existing flat cables without disconnection
Clip-together construction enables rapid assembly as a single unit
Optimized geometry for flat cable profiles to ensure secure fit

Applications

Electromagnetic interference suppression for flat ribbon cables
Signal integrity enhancement in data transmission lines
Common mode noise reduction in electronic assemblies

Procurement Notes

Verify the specific part number against official KEMET documentation to confirm dimensional accuracy and material specifications. Ensure compatibility with the target flat cable thickness and width before procurement. Cross-reference manufacturer datasheets for handling instructions and environmental ratings.

Selection Notes

Select this component when managing flat cables requiring non-invasive EMI mitigation. The split-core architecture facilitates retrofitting into existing harnesses. Confirm that the internal cavity dimensions accommodate the specific flat cable profile to maintain effective magnetic coupling and mechanical stability.

Part Context

This component belongs to KEMET's range of cable ferrites designed for EMI suppression. Unlike solid cores, split-core variants allow for post-assembly installation. The ESD-FPD-34 specifically targets flat cable geometries, providing a targeted solution for noise control in compact electronic interconnects.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify functional equivalence through dimensional and magnetic property comparison if considering alternative suppliers.
