ESD5V3U1U-02LS E6327

ESD5V3U1U-02LS E6327 is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Infineon Technologies. Its product description is TVS DIODE 5.3VWM 28VC PGTSSLP21. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for ESD5V3U1U-02LS E6327

• Description：TVS DIODE 5.3VWM 28VC PGTSSLP21
• Series：-
• Mfr：Infineon Technologies
• Package：Tape & Reel (TR),Cut Tape (CT)
• Type：Zener
• Bidirectional Channels：-
• Voltage - Reverse Standoff (Typ)：5.3V (Max)
• Voltage - Breakdown (Min)：6V
• Voltage - Clamping (Max) @ Ipp：28V (Typ)
• Current - Peak Pulse (10/1000µs)：3A (8/20µs)
• Power - Peak Pulse：-
• Power Line Protection：No
• Applications：Ethernet, HDMI
• Capacitance @ Frequency：0.4pF @ 1MHz
• Operating Temperature：-55°C ~ 125°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：0201 (0603 Metric)
• Supplier Device Package：PG-TSSLP-2-1
• Unidirectional Channels：1
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for ESD5V3U1U-02LS E6327
