ESDSBSLC5V0AE2-TP

ESDSBSLC5V0AE2-TP is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists MCC (Micro Commercial Components). Its product description is TVS DIODE 5VWM 10VC 0201A. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for ESDSBSLC5V0AE2-TP

• Description：TVS DIODE 5VWM 10VC 0201A
• Series：-
• Mfr：MCC (Micro Commercial Components)
• Package：Bulk
• Type：Zener
• Bidirectional Channels：-
• Voltage - Reverse Standoff (Typ)：5V (Max)
• Voltage - Breakdown (Min)：6V
• Voltage - Clamping (Max) @ Ipp：10V (Typ)
• Current - Peak Pulse (10/1000µs)：4A (8/20µs)
• Power - Peak Pulse：44W
• Power Line Protection：Yes
• Applications：General Purpose
• Capacitance @ Frequency：0.35pF @ 1MHz
• Operating Temperature：-55°C ~ 125°C (TJ)
• Mounting Type：Surface Mount
• Package / Case：0201 (0603 Metric)
• Supplier Device Package：0201-A
• Unidirectional Channels：2
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for ESDSBSLC5V0AE2-TP
