F-273U

Overview

The Triad Magnetics F-273U is an industrial control transformer designed for chassis mounting with wire leads. It features a single secondary winding configuration providing 24.0V CT at 12.0A, resulting in a maximum power rating of 240.0 VA. The primary side supports 115V input at 50/60 Hz frequencies. This component belongs to the F series and is classified as a power and audio transformer suitable for industrial applications requiring robust voltage transformation capabilities.

Feature Summary

• Chassis mount construction with integrated wire leads for direct connection
• Single secondary winding design offering center-tapped output
• Industrial grade classification for control transformer duties

Applications

• Industrial control systems
• Power supply circuits requiring 24V CT output
• Equipment needing 115V step-down transformation

Procurement Notes

Verify the specific lead length requirements against your chassis layout before ordering, as this model utilizes wire leads rather than PCB pins. Confirm that the 240 VA power rating aligns with your system's thermal management capabilities. Ensure the 115V primary voltage matches your available power source frequency specifications of 50 or 60 Hz to prevent operational issues.

Selection Notes

Select this model when a high-power industrial control transformer is required with a fixed 24V CT secondary output. It is appropriate for designs where chassis mounting is preferred over PCB integration. Consider the physical dimensions and weight constraints, as this unit is significantly heavier than standard low-power transformers. Verify compatibility with existing wiring harnesses due to the lead-based termination style.

Part Context

This component is part of Triad Magnetics' F series, which specializes in industrial control transformers. The F-273U represents a higher power variant within this lineup, distinguished by its 240 VA capacity compared to lower-rated models. It serves as a dedicated solution for applications demanding reliable voltage conversion in industrial environments.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Users should consult Triad Magnetics directly for equivalent alternatives if this specific model is unavailable.
