F-29U

Overview

The Triad Magnetics F-29U is a laminated core power transformer designed for chassis mounting with wire leads. It features a single primary winding rated for 115V input and operates at 50Hz or 60Hz frequencies. The unit provides a single secondary output with multiple voltage taps, specifically delivering 10V, 11V, and 12V center-tapped configurations. The transformer supports a maximum current rating of 11A and has a total power capacity of 132VA. This component utilizes standard isolation techniques suitable for general industrial power supply applications requiring robust mechanical mounting.

Feature Summary

• Chassis mount construction with integrated wire leads for direct circuit connection
• Single primary winding compatible with 115V AC input sources
• Multi-tap secondary configuration providing selectable 10V, 11V, or 12V outputs
• Laminated core design optimized for 50Hz and 60Hz operational frequencies

Applications

• Industrial power supply units requiring chassis integration
• Audio equipment power stages utilizing center-tapped transformers
• Rectifier and filter circuit implementations in electronic systems
• General purpose AC to low-voltage DC conversion hardware

Procurement Notes

Verify the specific secondary voltage requirement against the available 10V, 11V, and 12V taps before procurement. Confirm that the 11A current rating aligns with the load demands of the target application. Ensure the chassis mounting dimensions and lead lengths are compatible with the enclosure design. Cross-reference the datasheet to confirm the 115V primary specification matches the local mains voltage standards.

Selection Notes

Select this model when a fixed 132VA capacity and 11A current limit are sufficient for the system. The multi-tap secondary allows flexibility in rectifier circuit design without requiring multiple transformer variants. Consider the physical size constraints associated with chassis mounting and wire lead routing. This component is appropriate for applications where vibration resistance provided by the chassis mount is necessary.

Part Context

The F-29U belongs to Triad Magnetics' series of single secondary chassis mount power transformers. These components are engineered for direct use in transformer, rectifier, or filter circuits within larger electronic assemblies. The product line emphasizes reliability and standardized mounting solutions for industrial and commercial power distribution needs.

Replacement Considerations

No public confirmed substitute part numbers are documented for this specific component. Users should verify electrical compatibility if considering alternative manufacturers.
