Product Detailed Parameters
- Description：PWR XFMR LAMINATED 24VA TH
- Series：Single Primary
- Mfr：Triad Magnetics
- Package：Box
- Type：Laminated Core
- Voltage - Primary：115V, 230V
- Voltage - Secondary (Full Load)：Parallel 14V, Series 28V
- Current - Output (Max)：Parallel 1.6A, Series 800mA
- Primary Winding(s)：Dual
- Secondary Winding(s)：Dual
- Center Tap：No
- Power - Max：24VA
- Mounting Type：Through Hole
- Termination Style：PC Pin
- Size / Dimension：41.28mm L x 57.15mm W
- Height - Seated (Max)：34.93mm
- Voltage - Isolation：1500Vrms
- Weight：0.832 lb (377.4 g)
Download product information
Overview
The Triad Magnetics F-375P is a board-mount power transformer designed for AC-to-AC voltage conversion. It features dual primary windings rated for 115V and 230V input, providing operational flexibility across standard mains voltages. The secondary output delivers 28.0V at 0.800A, with a center-tapped configuration (28.0Vct). With a power rating of 28VA, this component utilizes a laminated core construction and through-hole mounting style. It is suitable for applications requiring isolated power transformation in industrial or control environments.
Feature Summary
- Dual primary winding design supports both 115V and 230V AC input configurations
- Center-tapped secondary output provides 28.0V at 0.800A capacity
- Laminated core construction ensures efficient magnetic coupling and isolation
Applications
- Industrial control systems requiring isolated power supplies
- Electronic equipment utilizing 115V/230V AC mains input
- Circuit designs needing center-tapped transformer outputs
Procurement Notes
Verify the specific datasheet version to confirm insulation ratings and thermal characteristics relevant to your enclosure constraints. Ensure the PCB footprint matches the through-hole pin spacing specified in the mechanical drawings. Confirm that the 28VA power rating aligns with the peak current demands of the downstream circuitry to prevent saturation or overheating during operation.
Selection Notes
Select the F-375P when a 28VA board-mount solution is required for converting standard line voltages to a 28V center-tapped output. This component is appropriate for designs where space constraints favor through-hole mounting over surface mount alternatives. Consider the physical dimensions and lead length requirements to ensure compatibility with the target printed circuit board layout and chassis integration.
Part Context
The F-375P belongs to Triad Magnetics' series of general-purpose power transformers. These components are engineered for reliability in commercial and industrial applications. The part number indicates a specific power rating and voltage configuration within the manufacturer's broader portfolio of laminated core transformers designed for board-level integration.
Replacement Considerations
Hammond Manufacturing 160H40 is documented as a similar alternative.
