F-379P

Overview

The Triad Magnetics F-379P is a board-mount power transformer with a 24VA rating. It features dual primary windings for 115V and 230V operation. The secondary provides a center-tapped configuration, delivering 60V at 0.2A per winding. This component utilizes a laminated core design and is intended for through-hole mounting on printed circuit boards.

Feature Summary

• Dual primary winding capability supports both 115V and 230V input voltages
• Center-tapped secondary output provides flexible voltage configurations
• Laminated core construction ensures efficient power transfer

Applications

• Board-mount power supply circuits
• AC to DC conversion systems
• Electronic equipment requiring isolated power sources

Procurement Notes

Verify the specific pinout and mechanical dimensions against the official datasheet before integration. Confirm that the 24VA power rating aligns with the target application's load requirements. Ensure the PCB layout accommodates the through-hole termination style and thermal constraints associated with this transformer class.

Selection Notes

Select the F-379P when a compact, board-mount solution is required for low-power applications. Its dual primary design offers versatility for global voltage inputs. Consider the center-tapped secondary if split-rail or full-wave rectification is necessary for the downstream circuitry.

Part Context

This component belongs to Triad Magnetics' line of general-purpose power transformers. It is designed for standard industrial and commercial electronics where reliable isolation and moderate power delivery are essential. The part is distinct from audio or signal transformers in its focus on mains frequency power conversion.
