Product Detailed Parameters
- Description：PWR XFMR LAMINATED 25VA CHAS MT
- Series：Single Secondary
- Mfr：Triad Magnetics
- Package：Box
- Type：Laminated Core
- Voltage - Primary：115V
- Voltage - Secondary (Full Load)：2.5V
- Current - Output (Max)：10A
- Primary Winding(s)：Single
- Secondary Winding(s)：Single
- Center Tap：Yes
- Power - Max：25VA
- Mounting Type：Chassis Mount
- Termination Style：Wire Leads
- Size / Dimension：95.25mm L x 53.97mm W
- Height - Seated (Max)：57.94mm
- Voltage - Isolation：3000Vrms
- Weight：1.7 lbs (771.1 g)
Download product information
Overview
The Triad Magnetics F-3X is a laminated core industrial control transformer designed for chassis mounting. It features a dual primary winding configuration supporting 115 VAC and 230 VAC input voltages, providing operational flexibility across different power standards. The unit delivers a single secondary output of 2.5 VCT at a rated current of 10 A, resulting in a total power rating of 25 VA. Electrical connections are established via wire leads, facilitating integration into equipment enclosures.
Feature Summary
- Dual primary winding design enables compatibility with both 115 VAC and 230 VAC supply lines
- Chassis mount construction allows for secure installation within industrial control panels
- Wire lead termination provides flexible connection options for internal wiring harnesses
Applications
- Industrial control panel power distribution
- Equipment requiring low voltage secondary power sources
- Chassis-mounted electrical systems
Procurement Notes
Verify that the specific application requires a 25 VA rating and 2.5 VCT secondary output to ensure compatibility. Confirm that the chassis mounting style and wire lead termination meet the enclosure design requirements. Check for any regional shipping restrictions or RoHS compliance documentation needs prior to ordering.
Selection Notes
Select this model when a robust 25 VA isolation transformer is needed for industrial environments. The dual primary capability simplifies inventory management for global deployments. Ensure sufficient physical space exists for the chassis mount dimensions and adequate clearance for the wire leads during assembly.
Part Context
The F-3X belongs to the F series of industrial control transformers from Triad Magnetics. This series is characterized by laminated core construction and chassis mounting styles. It serves as a standard component for stepping down mains voltage to lower levels for control circuitry in heavy-duty applications.
Replacement Considerations
Hammond Manufacturing part number 166S2 is documented as a cross-reference substitute for the F-3X. Verify dimensional and electrical specifications match before implementation.
