F-54X

Overview

The Triad Magnetics F-54X is a laminated core power transformer designed for chassis mounting with wire leads. It features a single primary winding rated for 115VAC input and a single secondary winding providing 35VAC at 800mA output. The unit delivers a maximum power rating of 52.5VA and incorporates a 1500Vrms isolation voltage between windings. This industrial control transformer operates at standard frequencies and utilizes a flange mount style for secure installation in equipment enclosures.

Feature Summary

• Laminated core construction for reliable power transformation
• High dielectric isolation capability between primary and secondary circuits
• Chassis mount design with integrated wire leads for direct connection

Applications

• Industrial control panels requiring isolated power supplies
• Electronic equipment chassis integration
• General purpose power distribution in control systems

Procurement Notes

Verify the specific datasheet version to confirm compliance with current safety standards such as UL or CSA, as regulatory approvals may vary by production batch. Ensure that the physical dimensions and lead configurations match the target enclosure design before finalizing procurement orders. Cross-reference the manufacturer part number with authorized distributor catalogs to confirm availability and authenticity.

Selection Notes

Select this component when a 52.5VA capacity is required for 115VAC primary applications. The 35VAC secondary output suits low-voltage control circuits. Consider the chassis mount form factor and wire lead termination style for compatibility with existing wiring harnesses. Evaluate the 1500Vrms isolation requirement against system safety specifications to ensure adequate protection levels.

Part Context

The F-54X belongs to Triad Magnetics' range of industrial power transformers. It serves as a standard solution for converting mains voltage to lower AC voltages in controlled environments. The product line emphasizes durability and electrical isolation for robust industrial operations.

Replacement Considerations

The Hammond Manufacturing 266K35 is documented as a cross-reference substitute for the F-54X. Verify pinout compatibility and mechanical fit before implementation.
