F18107SDK1000

$161.05

Description：MODULE SCR/DIODE 105A 380VAC
Series：F18

SKU:e6af7d6fd10c Category: SCRs - Modules Brand: Sensata-Crydom

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：MODULE SCR/DIODE 105A 380VAC
Series：F18
Mfr：Sensata-Crydom
Package：Bulk,Box
Structure：Series Connection - All SCRs
Number of SCRs, Diodes：2 SCRs
Voltage - Off State：1 kV
Current - On State (It (AV)) (Max)：-
Current - On State (It (RMS)) (Max)：-
Current - Non Rep. Surge 50, 60Hz (Itsm)：2250A @ 60Hz
Operating Temperature：-40°C ~ 125°C (TJ)
Mounting Type：Chassis Mount
Package / Case：Module
Voltage - Gate Trigger (Vgt) (Max)：3 V
Current - Gate Trigger (Igt) (Max)：150 mA
Current - Hold (Ih) (Max)：-
Grade：-
Qualification：-

Download product information

F18107SDK1000

Overview

The F18107SDK1000 is a discontinued SCR module from the Sensata-Crydom F18 series. It features a standard industry package designed for power control applications. The device contains two SCRs in a serial configuration with an integrated diode, housed in a TO-240AA (SDK) module package. Key electrical ratings include a repetitive peak reverse voltage of 380 VAC and a maximum load current of 105 A. It supports screw mounting and operates within a junction temperature range of -40°C to 125°C.

Feature Summary

Integrates dual SCRs and a diode in a single serial-connected module structure
Utilizes the standard F18 industry package for versatile power control building blocks
Designed for robust base or panel mounting via screw terminals
Constructed using silicon technology for reliable high-power switching

Applications

Industrial power control systems
Solid-state power switching circuits
Heavy-duty AC load management
Power conversion equipment

Procurement Notes

This component is officially discontinued and no longer manufactured by Sensata-Crydom. Procurement should focus on identifying verified replacement parts rather than sourcing new inventory. Verify that substitute components match the original electrical specifications and mechanical footprint to ensure system compatibility. Consult official manufacturer documentation for approved alternatives.

Selection Notes

Selection requires evaluating equivalent modules with matching voltage and current ratings due to discontinuation. The SDK package form factor must be maintained for existing board layouts. Consider thermal management requirements as the original design assumed specific heat sinking capabilities. Ensure the replacement part maintains the same SCR/diode configuration and gate trigger characteristics for circuit stability.

Part Context

The F18107SDK1000 belongs to the Crydom F18 series, known for providing industry-standard packages that serve as modular building blocks for power electronics. This series typically offers nine circuits per package for flexible configuration. The SDK variant specifically denotes the TO-240AA housing style, widely used in industrial thyristor applications requiring high current density and reliable thermal performance.
