F2782Y001L-051

Overview

The F2782Y001L-051 is an LC (T-Type) EMI filter module designed for CAT5 data lines. It features a 5th order low-pass configuration with one channel and a current rating of 1.5 A. The component operates within a temperature range of -25°C to 85°C and includes an integrated Cat5 RJ45 plug interface.

Feature Summary

• Provides electromagnetic interference suppression for high-speed data transmission
• Integrates a Cat5 RJ45 plug for direct connection compatibility
• Utilizes a 5th order low-pass LC T-Type filter topology

Applications

• Data lines for mobile devices
• CAT5 network cabling systems
• RJ45 connected electronic equipment requiring EMI protection

Procurement Notes

Verify the specific suffix '051' against official ITG Electronics documentation to confirm the single-channel CAT5 specification. Ensure the operating temperature range of -25°C to 85°C meets environmental requirements. Confirm that the integrated RJ45 plug form factor aligns with the target assembly design before procurement.

Selection Notes

Select this component when a compact, integrated EMI solution for CAT5 interfaces is required. The 1.5 A rating suits standard data line applications. Consider the fixed RJ45 connector integration as a primary selection criterion over discrete filter components to simplify assembly and ensure consistent shielding performance in mobile device or network infrastructure contexts.

Part Context

This part belongs to the F2782Y Series from ITG Electronics, which offers EMI filters for CAT5 and CAT6a standards. The series provides both single-line and double-line configurations. The F2782Y001L-051 specifically addresses CAT5 applications with a single-channel design, distinguishing it from higher-channel variants like the F2782Y001L-052.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Verify compatibility with existing circuit designs if considering alternative manufacturers.
