F47AGCHA-G150U is listed in the Antennas RF range at ChipApex. The manufacturer field lists Airgain. Its product description is LTE FLEX ANTENNA. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for F47AGCHA-G150U
- Description：LTE FLEX ANTENNA
- Series：-
- Mfr：Airgain
- Package：Bag
- RF Family/Standard：Cellular
- Frequency Group：UHF (1GHz ~ 2GHz), UHF (2GHz ~ 3GHz)
- Frequency (Center/Band)：-
- Frequency Range：700MHz ~ 2.7GHz
- Antenna Type：-
- Number of Bands：-
- VSWR：2.5
- Return Loss：-
- Gain：3dBi
- Features：-
- Termination：U.FL
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：-
- Height (Max)：-
- Applications：-
- Power - Max：-
Antennas RF datasheet and documents for F47AGCHA-G150U
Antennas RF Overview
The Airgain F47AGCHA-G150U is a flexible PCB antenna designed for cellular and LTE applications. It operates within the frequency range of 699 MHz to 2.7 GHz, supporting standard LTE bands. The component features a U.FL connector for interface termination and includes a 150 mm cable length. Physical dimensions are specified as 67.0 x 58.0 x 0.2 mm with a grey finish. The antenna provides a gain of 3 dBi and maintains a VSWR of 10.
Antennas RF Feature Summary
- Flexible PCB construction suitable for embedded integration in compact wireless devices
- Broadband coverage supporting cellular frequencies from 699 MHz to 2.7 GHz
- Integrated U.FL connector with fixed 150 mm cable length for direct RF interface
Antennas RF Applications
- LTE-enabled IoT modules requiring embedded connectivity
- Industrial wireless communication devices
- Portable cellular data terminals
Antennas RF Procurement Notes
Verify that the specific part number matches the required frequency band and connector type for your design. Confirm physical clearance for the 67.0 x 58.0 mm footprint and 150 mm cable routing. Ensure compatibility with the U.FL interface on the host board. Cross-reference official datasheets for environmental ratings and mounting requirements before finalizing procurement.
Antennas RF Selection Notes
Select this model when a low-profile, flexible form factor is required for cellular integration. The 3 dBi gain and broadband range suit general LTE operations. Consider the fixed cable length and U.FL termination for system layout constraints. Evaluate space limitations against the 0.2 mm thickness profile. This component is appropriate for designs prioritizing flexibility over high-gain performance.
Antennas RF Part Context
This antenna belongs to Airgain's embedded solution portfolio for wireless devices. It supports LTE and cellular communications in industrial and IoT contexts. The product line emphasizes smart coverage optimization for enterprise and transportation applications. Integration typically involves custom RF tuning and design support provided by the manufacturer.
Antennas RF Replacement Considerations
The related model F47AGBWA-G150U shares similar specifications but may differ in color or minor physical attributes. Verify exact dimensional tolerances and connector orientation when substituting. Consult official documentation to confirm functional equivalence regarding frequency response and impedance matching.
