FA-365 32.0000MB-C

Crystals Overview

The FA-365 32.0000MB-C is a surface-mount crystal oscillator manufactured by Epson. It operates at a fundamental frequency of 32 MHz with a frequency tolerance of ±50 ppm. The component features a load capacitance of 18 pF and an equivalent series resistance (ESR) of 50 Ohms. It utilizes a 2-SMD, no lead package with dimensions of 6.00 mm in length and 3.50 mm in width.

Crystals Feature Summary

• Provides stable frequency generation for digital circuits
• Designed for surface-mount technology integration
• Offers precise timing accuracy within specified tolerance limits

Crystals Applications

• General purpose clock sources for microprocessors
• Timing references for communication interfaces
• Clock signals for consumer electronic devices

Crystals Procurement Notes

Verify the specific suffix codes against official Epson documentation to ensure correct frequency and tolerance specifications. Confirm package compatibility and mounting requirements prior to procurement. Cross-reference part numbers with authorized distributors to avoid counterfeit components. Ensure environmental ratings meet application standards.

Crystals Selection Notes

Select this component when a 32 MHz fundamental frequency is required for system timing. Consider the ±50 ppm tolerance for applications with moderate stability needs. Evaluate the 18 pF load capacitance requirement against the host circuit design. Assess the physical footprint constraints against available PCB space.

Crystals Part Context

This part belongs to the FA-365 series of surface-mount crystals from Epson. The series offers various frequency options within a standardized small outline package. It serves as a reliable timing element for embedded systems requiring compact form factors and consistent performance across operating conditions.

Crystals Replacement Considerations

Direct substitutes must match the 32 MHz frequency, 18 pF load capacitance, and 2-SMD package dimensions. Verify equivalent ESR values and frequency stability tolerances. Consult manufacturer cross-reference lists for approved alternatives ensuring identical electrical characteristics and mechanical fit.
