FBH201209T-520Y-S

Chip Ferrite Bead Overview

The FBH201209T-520Y-S is a multilayer ferrite chip EMI suppressor manufactured by Cal-Chip Electronics, Inc. It operates within a temperature range of -55°C to +125°C and features a maximum DC resistance of 30mΩ. The component provides an impedance of 52 Ohms at 100 MHz and supports a current rating of 3A. Housed in a surface-mount 0805 (2012 Metric) package with dimensions of 2.0mm length, 1.25mm width, and 0.9mm height, it is designed for flow, reflow, and wave soldering applications.

Chip Ferrite Bead Feature Summary

• Multilayer technology providing high electrode strength and solder heat resistance
• Eliminates the need for wiring by direct PCB mounting for EMI/RFI attenuation
• Optimized for surface mounting equipment with outstanding solderability

Chip Ferrite Bead Applications

• Power line filtering in electronic equipment
• EMI/RFI suppression circuits
• Surface mount assembly processes

Chip Ferrite Bead Procurement Notes

Verify the specific impedance value and current rating against the official manufacturer datasheet before integration. Confirm that the 0805 package dimensions align with your PCB footprint requirements. Ensure the operating temperature range meets your environmental specifications. Check RoHS compliance status if required by your manufacturing standards. Validate the supplier's authorization to guarantee component authenticity.

Chip Ferrite Bead Selection Notes

Select this component when high current handling capability is required alongside effective noise suppression. The low DC resistance minimizes power loss in power lines. The multilayer construction offers robust mechanical stability for automated assembly. Consider the 100 MHz impedance specification for target frequency attenuation needs. Ensure the surface-mount form factor fits the available board space constraints.

Chip Ferrite Bead Part Context

This ferrite bead belongs to the FBH series from Cal-Chip Electronics, Inc., which utilizes multilayered magnetic materials for EMI suppression. The series is engineered for surface mounting applications, offering superior performance compared to conventional beads. These components are designed to provide high impedance while maintaining structural integrity during soldering processes.

Chip Ferrite Bead Replacement Considerations

Consult the official Cal-Chip Electronics catalog for verified substitute part numbers within the FBH series or equivalent product lines. Cross-reference impedance values, current ratings, and package dimensions to ensure functional compatibility. Do not assume interchangeability without verifying technical specifications against the original component datasheet.
