FCXO-07F24.00MVdd0.9V20ppm-40C+105C-B

Oscillators Overview

The FCXO-07F24.00MVdd0.9V20ppm-40C+105C-B is a 24 MHz CMOS crystal oscillator from the FCXO-07F series by River Eletec Corporation. It operates at an ultra-low supply voltage of 0.9 V and delivers a frequency stability of ±20 ppm across an industrial temperature range of -40°C to +105°C. The device features a standby power-down function and is housed in a compact 4-SMD, No Lead package with dimensions corresponding to the 1612 metric size. It utilizes robust ceramic packaging with a metal lid for enhanced reliability.

Oscillators Feature Summary

• Ultra-low supply voltage operation down to 0.9 V
• Instant clean clock signal output upon power-up
• Robust ceramic package construction with metal lid

Oscillators Applications

• Battery-powered portable electronic devices
• High-frequency clock signal generation
• Reliable timekeeping systems

Oscillators Procurement Notes

Verify the specific voltage and tolerance suffixes against the required system specifications. Confirm the operating temperature range matches the application environment. Ensure the 4-SMD package footprint aligns with the PCB design. Cross-reference the manufacturer part number with official distributor catalogs to confirm current product status and availability.

Oscillators Selection Notes

Select this component when ultra-low voltage operation at 0.9 V is required alongside high-temperature stability up to 105°C. The 20 ppm frequency stability suits applications needing precise timing without excessive power consumption. Consider the 1612 size constraint for space-limited designs requiring a CMOS output interface.

Oscillators Part Context

This model belongs to the FCXO-07F series of high-frequency oscillators designed for low-power applications. The series offers various voltage options ranging from 0.9 V to 1.5 V and different frequency stabilities. The 24 MHz output frequency is standard for many digital communication and processing interfaces.

Oscillators Replacement Considerations

Compatible variants within the same series include models with different supply voltages such as 1.2 V or 1.0 V, and varying frequency tolerances like 30 ppm or 50 ppm. Temperature ranges may also differ, such as -40°C to +85°C. Verify that any substitute maintains the 24 MHz frequency and CMOS output type.
